Features:

SUPPORT Pit Mode

7-24V input, 5V output for your camera

25mW/200mW/400mW/600mW power switchable

0.01mW parameter-adjusting Mode, power with zero interference

MMCX UFL connector, One button setup channel/band/power

With MIC, OSD configuration using Smart audio

Specifications:

Input voltage: 7V-24V

Power supply: 5V Camera @ under 0.3A max.

Output power: 25mW: 100mA

200mW: 200mA

400mW: 250mA

600mW: 320mA @12V

Range: Up to 2 km with omnidirectional RHCP antennas

Port connector: Solder Pads

Antenna connector: MMCX/U.FL

Dimensions: 26(W)x26(D)mm,20x20mm(hole)

Weight:5.4g(excluding antenna)

Package includes:

1x FX3-ultimate

1x Cable

1x MMCX Antenna

1x Product manual

Notice: 5645,5925,5945(E4,E7,E8) channels are not available due to FCC regulation.

Selecting 5645/5925/5945(E4/E7/E8) will be invalid action.

Please read the Info before purchasing.

Due to the equipment need being sold under the FCC’s amateur radio rules.

This product requires an amateur radio license to operate legally in the US.

Operators must abide by all applicable laws and hold an amateur license to operate this equipment.

Use of amateur equipment without a license could subject the operator to significant fines by the FCC.
