- MULTIPLE FUSE TERMINALS: The WWX-FUSE DIST BLOCK from Wet Sounds features multiple fuse terminals that allow for easy distribution of power to multiple components. The block is capable of holding up to 3 fuses, each with a maximum rating of 100 amps.
- CLEAR COVER: The fuse distribution block comes with a clear cover that allows for easy inspection of the fuses and their connections. The cover also helps to protect the fuses from damage and moisture.
- HIGH-QUALITY CONSTRUCTION: Wet Sounds uses high-quality materials to construct the WWX-FUSE DIST BLOCK, ensuring long-lasting performance and reliability. The block is built to withstand harsh marine environments, making it a great choice for boats and other watercraft.
- EASY INSTALLATION: The WWX-FUSE DIST BLOCK is designed for easy installation and comes with all the necessary hardware. The block can be mounted in a variety of positions and orientations, making it easy to integrate into your existing system.
- VERSATILE APPLICATIONS: The WWX-FUSE DIST BLOCK is a versatile component that can be used in a wide range of applications, including marine, automotive, and industrial systems. Whether you need to distribute power to multiple amplifiers or protect sensitive electronics, the WWX-FUSE DIST BLOCK is an excellent choice.
Tighten-up your wiring Wet Sounds' Wet Wire WWX-FUSE fused distribution block will help keep your system's power and ground wiring tight, secure, safe, and neat. The tough, weather-resistant case features wire channels with openings for tie wraps that secure wires tightly to the distribution block. Wet Sounds designed this block specifically for marine and car applications - it protects the fuse from heat and moisture, and features nickel-plated contacts for long-lasting, corrosion-free connections. Versatile distribution The two inputs fit 1/0-gauge wire, or 4-gauge using the included reducer inserts. The four outputs fit 4-gauge wires, 8-gauge with the reducers. Wet Sounds also includes a number of jumpers you use to connect adjacent conductors together, where fuses aren't needed or desired, in order to configure the distribution of power for your particular setup. Convertible configurations There are a lot of ways to configure this fused distribution block, including: Power for 2 amps: 1 power in with jumper, 2 ANL fuses, 2 power outs Power for 3 amps: 1 power in with jumper, 1 ANL fuse and 2 mini-ANL fuses, 3 power outs Power for 4 amps: 1 power in with jumper, 4 mini-ANL fuses, 4 power outs Power and ground for 1 amp: 1 power and 1 ground in, 1 ANL fuse and jumper, 1 power and 1 ground out Power and ground for 2 amps: 1 power and 1 ground in, 2 mini-ANL fuses and jumper, 2 power and 2 ground outs Warning: Connecting jumpers incorrectly could bypass a fuse or make a short circuit, possibly creating a dangerous fire hazard.
- Is Discontinued By Manufacturer : No
- Package Dimensions : 7.9 x 5.2 x 2 inches; 1.8 Pounds
- Date First Available : June 14, 2018
- Manufacturer : Wet Sounds
